• ASRock Super Alloy
  - Sapphire Black PCB
  - High Density Glass Fabric PCB
  ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  ASRock Live Update & APP Shop
• - Supports 9^th and 8^th Gen Intel^® Core™ Processors (Socket 1151)
  - Supports CPU up to 95W
  - 5 Power Phase design
  - Supports Intel^® Turbo Boost 2.0 Technology
• - Intel^® H310
• - Dual Channel DDR4 Memory Technology
  - 2 x DDR4 DIMM Slots
  - Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
  - Max. capacity of system memory: 64GB*
  - Supports Intel^® Extreme Memory Profile (XMP) 2.0
  - 15μ Gold Contact in DIMM Slots


  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  - ACPI 6.0 Compliant wake up events
  - SMBIOS 2.7 Support
  - DRAM, PCH 1.05V Voltage Multi-adjustment
• - Supports Intel^® UHD Graphics Built-in Visuals : Intel^® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® Insider™, Intel^® UHD Graphics
  - DirectX 12
  - HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
  - Three graphics output options: D-Sub, DVI-D and HDMI**
  - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
  - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
  - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
  - Supports HDCP 2.2 with DVI-D and HDMI 1.4 Ports
  - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port


  *Intel^® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
  **Supports up to 2 displays simultaneously
• - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
  - Supports Surge Protection
  - ELNA Audio Caps


  *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
• - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - 1 x Realtek RTL8111H
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• - 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
  - 1 x PCI Express 2.0 x1 Slot

• Storage
  - 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
• - 1 x TPM Header
  - 1 x Chassis Intrusion and Speaker Header
  - 1 x CPU Fan Connector (4-pin)
  - 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector
  - 1 x Front Panel Audio Connector
  - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
  - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)


  *The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
  **The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
  CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
• - 1 x PS/2 Mouse/Keyboard Port
  - 1 x D-Sub Port
  - 1 x DVI-D Port
  - 1 x HDMI Port
  - 4 x USB 2.0 Ports (Supports ESD Protection)
  - 2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Line in / Front Speaker / Microphone
• Software
  - ASRock A-Tuning
  - ASRock XFast LAN
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock Instant Flash
  - ASRock Internet Flash


  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables
• - Temperature Sensing: CPU, Chassis/Water Pump Fans
  - Fan Tachometer: CPU, Chassis/Water Pump Fans
  - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans
  - Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans
  - CASE OPEN detection
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• - Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
  - Solid Capacitor design
• - Microsoft^® Windows^® 10 64-bit
• - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)

• ASRock Super Alloy
  - Premium 45A Power Choke
  - Dual-Stack MOSFET (DSM)
  - High Density Glass Fabric PCB
  ASRock 802.11ac WiFi
  ASRock Full Spike Protection
  ASRock Live Update & APP Shop
• - Supports 7^th and 6^th Generation Intel^® Core™ i7 / i5 / i3 / Pentium^® / Celeron^® Processors (Socket 1151)
  - Digi Power design
  - 6 Power Phase design
  - Supports Intel^® Turbo Boost 2.0 Technology
• - Intel^® H170
  - Supports Intel^® Small Business Advantage 4.0
• - Dual Channel DDR4 Memory Technology
  - 2 x DDR4 DIMM Slots
  - Supports DDR4 2133 non-ECC, un-buffered memory
  - Supports ECC UDIMM memory modules (operate in non-ECC mode)
  - Max. capacity of system memory: 32GB*
  - Supports Intel^® Extreme Memory Profile (XMP) 2.0


  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  - ACPI 5.0 Compliant wake up events
  - SMBIOS 2.7 Support
  - CPU, GT_CPU, DRAM, PCH 1.0V, VCCIO, VPPM, VCCSA Voltage Multi-adjustment
• - Supports Intel^® HD Graphics Built-in Visuals : Intel^® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® Insider™, Intel^® HD Graphics 510/530
  - Pixel Shader 5.0, DirectX 12
  - Max. shared memory 1024MB*
  - Dual graphics output: Support DVI-D and HDMI ports by independent display controllers
  - Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz
  - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports Accelerated Media Codecs: HEVC, VP8, VP9
  - Supports HDCP with DVI-D and HDMI Ports
  - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports


  *The size of maximum shared memory may vary from different operating systems.
  **Intel^® HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
  ***Due to chipset limitation, the Blu-ray playback of Intel^® HD Graphics is only supported under Windows^® 8 / 8 64-bit / 7 / 7 64-bit.
  ****Intel^® InTru™ 3D is only supported under Windows^® 8 / 8 64-bit / 7 / 7 64-bit.
• - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
  - Premium Blu-ray Audio support
  - Supports Surge Protection (ASRock Full Spike Protection)
  - ELNA Audio Caps


  *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
• - 1 x Intel^® I219V (Gigabit LAN PHY 10/100/1000 Mb/s)
  - 1 x Realtek RTL8111H (PCIE x1 Gigabit LAN 10/100/1000 Mb/s)
  - Supports Wake-On-WAN (on Realtek RTL8111H)
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
  - Supports LAN Cable Detection (on Realtek RTL8111H)
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• - Supports IEEE 802.11a/b/g/n/ac
  - Supports Dual-Band (2.4/5 GHz)
  - Supports high speed wireless connections up to 433Mbps
  - Supports Bluetooth 4.0 / 3.0 + High speed class II
• - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
  - 1 x Vertical Half-size Mini-PCI Express Slot: For WiFi + BT Module**


  *Supports NVMe SSD as boot disks
  **This Mini-PCI Express Slot supports WiFi and mSATA devices.
• - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 14 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug
  - 1 x mSATA Connector (shared with Mini-PCI Express Slot), support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 14 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug
• - 1 x TPM Header
  - 1 x Chassis Intrusion Header
  - 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)
  - 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)*
  - 1 x 20 pin ATX Power Connector
  - 1 x 4 pin 12V Power Connector
  - 1 x Front Panel Audio Connector
  - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))


  *All CPU/Chassis Fan Connectors can auto detect if 3-pin or 4-pin fan is in use.
  The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
• - 1 x PS/2 Mouse/Keyboard Port
  - 1 x DVI-D Port
  - 1 x HDMI Port
  - 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 6 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Line in / Front Speaker / Microphone
• Software
  - ASRock A-Tuning
  - ASRock Disk Health Report
  - ASRock USB Key
  - ASRock APP Charger
  - ASRock XFast LAN
  - ASRock XFast RAM
  - ASRock Fast Boot (Fast Boot, Restart to UEFI)
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock Instant Flash
  - ASRock Internet Flash
  - ASRock Crashless BIOS
  - ASRock OMG (Online Management Guard)
  - ASRock UEFI System Browser
  - ASRock UEFI Tech Service
  - ASRock Easy RAID Installer
  - ASRock Easy Driver Installer


  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables
  - 1 x WiFi-802.11ac Module
  - 2 x SMA WiFi Antenna Cables
  - 2 x ASRock WiFi 2.4/5 GHz Antennas
  - 1 x WiFi Module Bracket
  - 2 x Screws for WiFi Module
• - CPU, Chassis temperature sensing
  - CPU, Chassis Fan Tachometer
  - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
  - CPU, Chassis Fan multi-speed control
  - CASE OPEN detection
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
  - Solid Capacitor design
• - Microsoft^® Windows^® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit*


  *To install Windows^® 7 OS, a modified installation disk with xHCI drivers packed into the ISO file is required. Please see our online tutorial or check our User Manual for more detailed instructions.
  For the updated Windows^® 10 driver, please visit ASRock's website for details.
• - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)
