This Haynes Scooter Repair Manual covers a range of Twist-and-Go Scooters powered by 50 to 250cc engines with automatic transmissions. Brands mentioned in the manual include Honda, MBK, Piaggio, Suzuki, Vespa and more. The Haynes manual is written for DIY home mechanics and features user-friendly directions, simple terms and helpful tips to get the job done.
The Haynes Scooter Repair Manual is more than just a how-to guide to fixing your scooter's mechanical issues. It also includes a section on buying spare parts and daily pre-ride checks to make sure your scooter is working properly and will safely get you from point A to point B. The manual also includes sections on maintenance, repairs and more. This book makes a great reference guide for first-time scooter owners and is an invaluable addition to any gear head's collection.

Haynes Twist-and-Go scooter manuals cover the following brands and models:

  • Aprilia
    SR50 1994-1999, Rally 50, Sonic FT and GP, and Leonardo 125.
  • Gilera
    Ice 50, Runner 50, Runner FX125, Runner FXR180, Runner VX125, Runner VXR180/200, SKP (Stalker).
  • Honda
    FES125 Pantheon, FES250 Foresight, NES125, @ 125, SFX50, SGX50 Sky, SH50/125, SZX50 (X8R-S/X8R-X).
  • Malaguti
    F12 Phantom 50, F12 Spectrum 50, F15 Firefox 50, Madison 125/150.
  • MBK
    Doodo 125, Mach G50, Nitro 50/100, Ovetto 50/100, Rocket, Skyliner 125, Stunt 50, Thunder 125.
  • Peugeot
    Elyseo 50/100/125, Looxor 50/100/125/150, Speedfight 50/100, Speedfight 2 50/100, Trekker 50/100, Vivacity 50/100, Zenith.
  • Piaggio
    B125 (Beverly), Hexagon 125, Super Hexagon 125, Super Hexagon 180, Liberty 125, NRG, Skipper, Skipper ST, Typhoon 50/80/125, X9 125, Zip 50, Zip 50 SP, Zip 125.
  • Suzuki
    AN125, AP50, AY50 Katana, UH125 Burgman.
  • Sym
    DD50 City Trek, Jet 50/100, Shark 50, Super Fancy and City Hopper.
  • Vespa
    ET2 4T 50, ET2 50, ET4 125, GT125/200.
  • Yamaha
    CS50 JogR, CW/BW 50, EW50 Slider, XN125 Teo's, XQ125 Maxster, YN50/100 Neos, YP125 Majesty, YQ50/100 Aerox.
150cc pit bike engine
Book Excerpt: Scooter Repair Manual: 50 to 250cc with Carburetor Engine Twist-and-Go Scooters

INSPECTION

  • To assess the condition of the big-end bearing, hold the crankshaft assembly firmly and push and pull on the connecting rod, checking for any up-and-down freeplay between the two (see illustration). If any freeplay is noted, the bearing is worn and either the bearing or the crankshaft assembly will have to be renewed. Note: A small amount of big-end side clearance (side-to-side movement) is acceptable on the connecting rod. Consult a scooter dealer about the availability of parts. Note: If a new bearing is available, fitting it is a specialist task which should be left to a scooter dealer or automotive engineer.
  • Inspect the crankshaft where it passes through the main bearings for wear and scoring. The shaft should be a press fit in the bearings; if it is worn or damaged a new assembly will have to be fitted. Evidence of extreme heat, such as discoloration or blueing, indicates that lubrication failure has occurred. Be sure to check the oil pump and bearing oil ways before reassembling the engine.
  • If available, place the crankshaft assembly on V-blocks and check the runout at the main bearing journals (B and C) and at either end (A and D) using a dial gauge (see illustration). If the crankshaft is out-of-true it will cause excessive engine vibration. If there is any doubt about the condition of the crankshaft have it checked by a scooter dealer or automotive engineer. Note: The crankshaft assembly is pressed together and is easily damaged if dropped.
  • Inspect the threads on each end of the crankshaft and ensure that the retaining nuts for the alternator rotor and the variator are a good fit (see illustration). Inspect the splines for the variator pulley on the left-hand end of the shaft. Inspect the taper and the slot in the right-hand end of the shaft for the alternator Woodruff key (see illustration). Damage or wear that prevents the rotor from being fitted securely will require a new crankshaft assembly.
  • Where applicable, inspect the oil pump drivegear teeth on the crankshaft and on the pump driveshaft for damage or wear (see illustration). Inspect the ends of pump driveshaft where it runs in its bearings. Renew any components that are worn or damaged.
